17" LCD 1U Rackmount Keyboard 16-Port KVM


Key Features

  • 1U LCD Keyboard drawer with 17" LCD panel
  • Anodized aluminium front panel
  • Built in on screen display controlled by integral membrane switches
  • Build in slide rail and mounts easily in any 19" cabinet
  • EMC shielding around the monitor housing to minimize interference
  • All mounting hardware included
  • Integrated, high-quality touchpad
  • Operating life of individual keys : 20 million operations
  • Built in KVM switch function for easy controlling and monitoring up to 16 servers/platforms
  • Auto scan mode for monitoring PCs and flexible scan time from 5-99 seconds
  • Supplied with sixteen cables - 6ft long
  • Product dimension 17.4(W) x 1.73(H) x 22.8(D)inch

Product Details

  • Samsung 17¨LCD Panel
  • Resolution
    1280 x 1024
  •  Control
    • OSD Control
      Brightness, Contrast, Colour, Clock,
      H.Position, V.Position, Phase, Scaling,
      Auto config, Input select, Multi window,
      Clear EEPROM, OSD adjust, Save
  • External Connection
    •  Power Input
      12V/5A DC adapter
    • Video Input
      15-pin D-Sub connectors
