Cincoze Intel Atom E3845 Processor Fanless Embedded Computer
$560.00
SKU
DC-1100
Cincoze Intel® Atom™ E3845 Quad Core Compact Size Fanless Computer and 2x Mini-PCIe Expansion
PRODUCTS FEATURES
- Onboard Intel® Atom™ E3845 Processor Quad Core, 1.91GHz
- 1x DDR3L SO-DIMM Max. up to 8 GB
- Dual Independent Display from 1x DVI-I and 1x DisplayPort
- 2x Intel® GbE port support Wake-on-LAN and PXE
- 1x USB 3.0, 3x USB 2.0
- 4x RS232/422/485 port with 5V/12V power
- 4x Isolated DI, 4x Isolated DO
- 1x 2.5” SATA SSD/HDD bay
- 1x CFast card and 1x SIM card socket
- 9~48VDC power input, support AT/ATX mode
- 2x Mini-PCIe slot for Wi-Fi / GSM / I/O expansion
- Universal I/O bracket for Mini-PCIe expansion
- E-Mark (E13, No.10R-0514062) Certified
DC-1100 is a high performance compact size 185mm (W) x 131mm (D) x 54mm (H) system designed with onboard Intel® Atom™ E3845 Quad Core 1.91GHz processor, rich I/O, an unique expansion capability, and supports wide range (9~48V) DC power input.
It supports the latest USB 3.0 technology. With features including completely cable-less designed, special heat dissipation, anti-vibration, and industrial components selection, DC-1100 is a ruggedized system that can operate in a harsh environment.
A build in voltage protection, reliable DC power input, and reverse power protection make DC-1100 a safety system for industrial applications.
- CPU
- Intel® Atom™ E3845, 1.91 GHz, Quad Core
- Memory
- DDR3L 1066 / 1333MHz (un-buffered and non-ECC)
- Max. Capacity 8 GB
- Socket 1x 204-Pin SO-DIMM
- Display
- VGA Yes (with optional split cable)
- 1x DVI
- 1x 1DisplayPort Connector (2560 x 1600)
- Multiple Display Dual
- Expansion
- PCI -
- PCIe -
- Mini PCIe 2x Full-size Mini PCIe
- Ethernet
- GbE1: Intel® I210
- GbE2: Intel® I210
- Support Wake-on-LAN and PXE
- Speed 10/100/1000 Mbps
- WatchDog Timer Software Programmable Supports 256 Levles System Reset
- Storage
- SSD / HDD 1x 2.5" SATA HDD Bay
- CompactFlash/CFast 1x CFast
- SIM Socket 1
- I/O Ports
- USB
- 1x 5Gbps USB 3.2 Gen1, Type A
- 3x 480Mbps USB 2.0, Type A
- DIO 4 in/4 out
- COM Port 4x RS-232/422/485
- USB
- Remote Power On/Off and Remote Power Reset -
- Power
- Power Type AT, ATX
- Power Supply Voltage 9~48VDC
- Connector 3-pin Terminal Block
- Power Adaptor Optional AC/DC 12V/5A, 60W
- Environment
- Operating Temperature -25°C to 70°C
- (With extended temperature peripherals; Ambient with Air Flow by IEC60068-2-1, IEC60068-2-2, IEC60068-2-14)
- Storage Temperature -30°C to 85°C
- Relative Humidity 10%~95% (Non-Condensing)
- Operating Temperature -25°C to 70°C
- Shock 50 Grms
- (With SSD According to IEC 60068-2-27, Half Sine, 11ms Duration)
- Vibration: Random 5 Grms
- (With SSD According to IEC 60068-2-64, 5~500Hz, 1 hr/axis)
- EMC
- CE, UKCA, FCC, ICES-003 Class A
- E-mark
- EMI
- CISPR 32 Conducted & Radiated: Class A
- EN/BS EN 55032 Conducted & Radiated: Class A
- EN/BS EN IEC 61000-3-2 Harmonic current emissions: Class A
- EN/BS EN61000-3-3 Voltage fluctuations & flicker
- FCC 47 CFR Part 15B, ICES-003 Conducted & Radiated: Class A
- EMS
- EN/IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kV
- EN/IEC 61000-4-3 RS: 80 MHz to 1000 MHz: 3 V/m
- EN/IEC 61000-4-4 EFT: AC Power: 1 kV; DC Power: 0.5 kV; Signal: 0.5 kV
- EN/IEC 61000-4-5 Surges: AC Power: 2 kV; Signal: 1 kV
- EN/IEC 61000-4-6 CS: 3V
- EN/IEC 61000-4-8 PFMF: 50 Hz, 1A/m
- EN/IEC 61000-4-11 Voltage Dips & Voltage Interruptions: 0.5 cycles at 50 Hz
- Physical
- Dimension (WxDxH) 185 x 131 x 56.15 mm
- Weight 1.58 kg
- Construction Extruded Aluminum with Heavy Duty Metal
- Wall Mount
- Optional Side / VESA / DIN-Rail Mounting
- Operating System
- Windows® 10
- Windows® 8.1
- Windows® 7
